Placa de baza Gigabyte B760I AORUS PRO LGA1700

Name: Placa de baza Gigabyte B760I AORUS PRO LGA1700
SKU: B760I AORUS PRO D4
Availability: InStock

SKU: B760I AORUS PRO D4

Producator: Gigabyte

Favorite

De ce să alegi LEADtech.ro?

Plata online
cu cardul
vezi detalii

Comenzi predate curierului in aceeasi zi pana in ora 15:00 vezi detalii

Retur in 14 zile
vezi detalii

Ai o intrebare?
Suna la 0756824557
vezi detalii

Disponibilitate:

În stoc

1.020,98 lei ~~1.121,99 lei~~

În stoc

in stoc

Favorite

Compara

Descriere

Placa de baza Gigabyte B760I AORUS PRO LGA1700, 2x DDR4, 1x HDMI, 1x DisplayPort, 1x PCIe 4.0 x16, 2x M.2, 4x SATA 6Gbps, WIFI 6, mini-ITX

SKU: B760I AORUS PRO D4 Categorie: Placi de baza

Specificații

PCI	0
Serial-or-Paralel	No/No
Video-Connection	HDMI/DP
Wi-Fi	Yes
Onboard-CPU	No
Product colour	Black
Country of origin	China
RAID support	Yes
Component for	PC
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax)
Package weight	1.49 kg
USB connector type	USB Type-A, USB Type-C
Memory channels	Dual-channel
Depth	170 mm
Top Wi-Fi standard	Wi-Fi 6 (802.11ax)
Processor manufacturer	Intel
Maximum internal memory	64 GB
Ethernet LAN	Yes
HDMI ports quantity	1
Ethernet LAN (RJ-45) ports	1
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity	1
HDMI version	2.0
Bluetooth version	5.2
USB 2.0 ports quantity	2
Products per shipping (inner) case	1 pc(s)
Batteries included	Yes
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	4
Audio output channels	7.1 channels
Line-in	Yes
PCI Express x16 slots	1
Number of memory slots	2
Supported storage drive types	HDD & SSD
Supported memory types	DDR4-SDRAM
Number of M.2 (M) slots	2
S/PDIF out port	Yes
HDCP	Yes
DisplayPort version	1.2
Package depth	227 mm
DisplayPorts quantity	1
VGA (D-Sub) ports quantity	0
Parallel processing technology support	Not supported
DVI-D ports quantity	0
DirectX version	12.0
Windows operating systems supported	Windows 10 x64, Windows 11 x64
Model Chipset	B760
Gaming	Nu
Format	Mini-ITX
Soclu Procesor	Socket 1700
Tip Memorie	DDR4
Numar sloturi memorie	2
Memorie maxima	64 GB
Tip slot interfata grafica	PCIe 4.0 x16
Chipset audio integrat	Realtek
Canale audio	7.1
Wireless	Da
BLUETOOTH	Da
USB Type-C	Da
HDMI	Da
Thunderbolt	Nu
Sloturi M.2	2
RJ-45 LAN	1
Memory slots type	DIMM
Unbuffered memory	Yes
Supported storage drive interfaces	M.2, SATA III
USB 3.2 Gen 2 (3.1 Gen 2) connectors	0
Number of SATA III connectors	4
Front panel audio connector	Yes
ATX Power connector (24-pin)	Yes
CPU fan connector	Yes
EPS power connector (8-pin)	Yes
BIOS type	UEFI AMI
BIOS memory size	256 Mbit
Clear CMOS jumper	Yes
ECC сompatibility	ECC & Non-ECC
Number of HDDs supported	4
RAID levels	0, 1, 5, 10
Front panel connector	Yes
RGB LED pin header	Yes
WiFi-AP antenna jack	2
Ethernet interface type	2.5 Gigabit Ethernet
Motherboard chipset family	Intel
PC health monitoring	Fan, Temperature, Voltage, Water cooling
ACPI version	5.0
Desktop Management Interface (DMI) version	2.7
System Management BIOS (SMBIOS) version	2.7
Battery weight	3 g
Lithium weight per battery	0.07 g
Number of battery cells	1
Battery technology	Lithium-Manganese Dioxide (LiMnO2)
Battery type	CR2032
Height	35 mm
Processor socket	LGA 1700
Supported processor sockets	LGA 1700
Maximum resolution	4096 x 2304 pixels
Total number of SATA connectors	4
12V power connector	Yes
Cables included	SATA
Number of storage drives supported	6
USB 3.2 Gen 1 (3.1 Gen 1) connectors	2
Motherboard chipset	Intel B760 Express
Bundled software	Norton Internet Security
Chassis intrusion connector	Yes
Headphone outputs	2
USB 2.0 connectors	1
Audio connector	Yes
Maximum internal memory supported by processor	64 GB
Supported memory module capacities	1GB, 2GB, 4GB, 8GB, 12GB, 16GB, 32GB
Motherboard form factor	mini ITX
Width	170 mm
Supported memory clock speeds	5333 MHz
Package width	235 mm
Package height	95 mm
WLAN controller model	Killer Wi-Fi 6 AX1650
Producator	GIGABYTE
Garantie	36
