Placa de Baza GIGABYTE H610M D3W DDR4 LGA1700, 2x DDR4,

SKU: H610M D3W DDR4
Producator: Gigabyte

De ce să alegi LEADtech.ro?

Plata online
cu cardul
vezi detalii
Comenzi predate curierului in aceeasi zi pana in ora 15:00 vezi detalii
Retur in 14 zile
vezi detalii
Ai o intrebare?
Suna la 0756824557
vezi detalii
Disponibilitate:

În stoc

378,99 lei 441,99 lei

În stoc

in stoc
Credit module tbi bank 3.4.1

89.81 Lei x 4 rate

Descriere

Placa de Baza GIGABYTE H610M D3W DDR4 LGA1700, 2x DDR4, 1x DP 1x HDMI, 1x PCIE 4.0 x16 1x PCIE 3.0 x1 2x M.2, 4x SATA 6GB/s, mATX

SKU: H610M D3W DDR4 Categorie:

Specificații

PCI

0

Serial-or-Paralel

No/No

Video-Connection

HDMI

Wi-Fi

No

USB3

4-8

PCI-Ex1

1

PCI-Ex16

1

Onboard-CPU

No

Country of origin

China

Component for

PC

Windows operating systems supported

Windows 10, Windows 11

Package width

265 mm

Ethernet interface type

Gigabit Ethernet

Weight

770 g

Package height

54 mm

Memory channels

Dual-channel

Product colour

Grey

Processor manufacturer

Intel

Maximum internal memory

64 GB

Ethernet LAN

Yes

HDMI ports quantity

1

Ethernet LAN (RJ-45) ports

1

HDMI version

2.1

Microphone in

Yes

Products per shipping (inner) case

1 pc(s)

Batteries included

Yes

USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity

0

USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity

0

USB 2.0 ports quantity

4

Audio output channels

7.1 channels

PCI Express x1 (Gen 3.x) slots

1

Line-in

Yes

Audio Chip

Realtek ALC897

PCI Express x16 (Gen 4.x) slots

1

Number of memory slots

2

Supported storage drive types

HDD & SSD

Supported memory types

DDR4-SDRAM

LAN controller

Realtek RTL8111H

Number of M.2 (M) slots

1

Screws included

Yes

DisplayPort version

1.2

DisplayPorts quantity

1

VGA (D-Sub) ports quantity

0

Parallel processing technology support

Not supported

DVI-D ports quantity

0

DirectX version

12.0

Package depth

265 mm

Model Chipset

H610

Gaming

Nu

Format

Micro-ATX (mATX)

Soclu Procesor

Socket 1700

Tip Memorie

DDR4

Numar sloturi memorie

2

Memorie maxima

64 GB

Tip slot interfata grafica

PCIe 4.0 x16

Chipset audio integrat

Realtek

Canale audio

7.1

Wireless

Nu

BLUETOOTH

Nu

HDMI

Da

Thunderbolt

Nu

Sloturi M.2

2

RJ-45 LAN

1

Memory slots type

DIMM

Unbuffered memory

Yes

Supported storage drive interfaces

M.2, SATA III

USB 3.2 Gen 2 (3.1 Gen 2) connectors

0

Number of SATA III connectors

4

Front panel audio connector

Yes

ATX Power connector (24-pin)

Yes

CPU fan connector

Yes

Number of chassis fan connectors

2

EPS power connector (8-pin)

Yes

Motherboard form factor

micro ATX

BIOS type

UEFI AMI

Clear CMOS jumper

Yes

Width

244 mm

ECC сompatibility

ECC & Non-ECC

Number of HDDs supported

4

Front panel connector

Yes

TPM connector

Yes

Motherboard chipset family

Intel

PC health monitoring

Fan, Temperature, Voltage, Water cooling

Power source type

ATX

ACPI version

5.0

Desktop Management Interface (DMI) version

2.7

System Management BIOS (SMBIOS) version

2.7

Battery weight

3 g

Lithium weight per battery

0.07 g

Number of battery cells

1

Battery technology

Lithium-Manganese Dioxide (LiMnO2)

Battery type

CR2032

Height

35 mm

Bundled software

Norton® Internet Security (OEM version) LAN bandwidth management software

Processor socket

LGA 1700

Supported processor sockets

LGA 1700

BIOS memory size

128 Mbit

USB 3.2 Gen 1 (3.1 Gen 1) connectors

2

Serial port headers

1

1st M.2 largest key size

2280

USB 2.0 connectors

1

Number of storage drives supported

5

Number of EPS power connectors (8-pin)

1

Supported memory clock speeds

3200 MHz

Motherboard chipset

Intel H610

Number of CPU fan connectors

1

1st M.2 highest PCI Express generation

3.0

Maximum internal memory per slot

32 GB

Depth

220 mm

MB-Socket

1700

MB-Format

micro-ATX

RAM-Slots

2

USB Type-C

N/A

Package weight

800 g

Producator

GIGABYTE

Garantie

36
